Technical Specifications
Model:
8D20P1G
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Severe Duty
Horsepower Rating:
20 HP
Synchronous RPM:
3600 RPM
Rated RPM:
3535 RPM
Frame Size:
256T
Rated Supply Voltage:
575 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
B
Full Load Torque:
29.7
Rated Voltage:
575 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
91%
Construction:
Cast Iron
C Dimension:
25
Bearing Type:
45BC03J3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
18.4 A
