Technical Specifications
Model:
DL96
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
25 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1780 RPM
Frame Size:
324U
Rated Supply Voltage:
460 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
B
Full Load Torque:
73.8
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
93.6%
Construction:
Cast Iron
C Dimension:
30.9
Bearing Type:
55BC03JPP3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
28.4 A
