Technical Specifications
Model:
AGH10FL1
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Pool
Horsepower Rating:
1 HP
Synchronous RPM:
3600 RPM
Frame Size:
48Y
Rated Supply Voltage:
220-240 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Full Load Torque:
24.29
Rated Voltage:
230 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
B
Duty Cycle:
Continuous
C Dimension:
8.4
Bearing Type:
BALL/SAB
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
6.0/6.3 A
