Technical Specifications
Model:
C300P1WS
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
300 HP
Synchronous RPM:
3600 RPM
Rated RPM:
3570 RPM
Frame Size:
5010S
Rated Supply Voltage:
2300/4000 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
B
Full Load Torque:
441.1
Rated Voltage:
2300 V
Rated Voltage:
4160 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
95%
Construction:
Cast Iron
C Dimension:
67.6
Bearing Type:
6315-J/C3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
66/38 A
