Technical Specifications
Model:
FN99
Brand:
US Motors (Nidec)
Product Condition:
New
Horsepower Rating:
2 HP
Synchronous RPM:
1800 RPM
Frame Size:
145T
Rated Supply Voltage:
208-230/460 & 190/380 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
B
Full Load Torque:
6
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
380 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.25
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
86.5%
C Dimension:
9.9
Bearing Type:
–
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
5.9-5.7/2.8 A
