Technical Specifications
Model:
FD1AA4KCR
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
1 HP
Synchronous RPM:
900 RPM
Rated RPM:
850 RPM
Frame Size:
56YZ
Rated Supply Voltage:
230 V
Motor Enclosure Type:
Totally Enclosed Air Over (TEAO)
Rated Voltage:
230 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
B
Duty Cycle:
Continuous
C Dimension:
13.8
Bearing Type:
BALL
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
5.8 A
