Technical Specifications
Model:
FD1CPA2JH
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
1 HP
Synchronous RPM:
1800 RPM
Frame Size:
56H
Rated Supply Voltage:
115/208-230 V
Motor Enclosure Type:
Totally Enclosed Air Over (TEAO)
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1.4
Insulation Class:
F
Duty Cycle:
Continuous
C Dimension:
12.8
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
9.0/4.5 A
