Technical Specifications
Model:
FD2CM2PHZ
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
2 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1725 RPM
Frame Size:
56HZ
Rated Supply Voltage:
115/230 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
C
Full Load Torque:
97.3
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
78.5%
C Dimension:
14.2
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
20.0/10.0 A
