Technical Specifications
Model:
T063BBP1910015B
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
1.5 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1725 RPM
Frame Size:
145T
Rated Supply Voltage:
115/230 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
L
Full Load Torque:
73.09
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1.15
Insulation Class:
B
Duty Cycle:
Continuous
Efficiency:
81%
C Dimension:
14.2
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
16.2/8.1 A
