Technical Specifications
Model:
FD34CA1PZ
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
0.75 HP
Synchronous RPM:
3600 RPM
Rated RPM:
3450 RPM
Frame Size:
56Z
Rated Supply Voltage:
115/230 V
Motor Enclosure Type:
Totally Enclosed Air Over (TEAO)
Full Load Torque:
18.21
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
B
Duty Cycle:
Continuous
C Dimension:
10.3
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
11.0/5.5 A
