Technical Specifications
Model:
S055REY8243012B
Brand:
US Motors (Nidec)
Product Condition:
New
Horsepower Rating:
0.5 HP
Synchronous RPM:
1800 RPM
Frame Size:
48Z
Rated Supply Voltage:
115/208-230 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Motor Design Class:
N
Full Load Torque:
24.41
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1.25
Insulation Class:
B
Duty Cycle:
Continuous
Efficiency:
65%
C Dimension:
10.6
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
8.6/4.2-4.3 A
