Technical Specifications
Model:
P063FWT4375015B
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
0.75 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1725 RPM
Frame Size:
56
Rated Supply Voltage:
208-230/460 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
B
Duty Cycle:
Continuous
C Dimension:
11.8
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
3.0-3.0/1.5 A
