Technical Specifications
Model:
U14S3AC
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
0.25 HP
Synchronous RPM:
1200 RPM
Rated RPM:
1150 RPM
Frame Size:
56C
Rated Supply Voltage:
208-230/460 V
Motor Design Class:
B
Full Load Torque:
1.1
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.25
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
72%
Construction:
Aluminum
C Dimension:
10.8
Bearing Type:
6203-2Z-J/C3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
1.1-1.2/0.6 A
