Technical Specifications
Model:
U15L9C
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
3.75 HP
Horsepower Rating:
15 HP
Frame Size:
254T
Rated Supply Voltage:
460 V
Full Load Torque:
44.5
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.25
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
87.5%
Construction:
Aluminum
C Dimension:
23.8
Bearing Type:
6207-2Z-J/C3
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
18.6 A
