Technical Specifications
Model:
WD14AA2PZ7
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Washdown
Horsepower Rating:
0.25 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1700 RPM
Frame Size:
56YZ
Rated Supply Voltage:
115/230 V
Motor Enclosure Type:
Totally Enclosed Air Over (TEAO)
Full Load Torque:
16.51
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1
Insulation Class:
F
Duty Cycle:
Continuous
C Dimension:
10.8
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
3.5/1.7 A
