Technical Specifications
Model:
WD32C1JHC
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
Washdown
Horsepower Rating:
1.5 HP
Synchronous RPM:
3600 RPM
Rated RPM:
3450 RPM
Frame Size:
56HC
Rated Supply Voltage:
115/208-230 V
Motor Enclosure Type:
Totally Enclosed Fan Cooled (TEFC)
Motor Design Class:
L
Full Load Torque:
36.11
Rated Voltage:
230 V
Rated Voltage:
115 V
Phase:
Single Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
78.5%
C Dimension:
13.8
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
14.6/8.1-7.4 A
