Technical Specifications
Model:
P063AHB1314015B
Brand:
US Motors (Nidec)
Product Condition:
New
Motor Type:
General Purpose
Horsepower Rating:
0.75 HP
Synchronous RPM:
1800 RPM
Frame Size:
56H
Rated Supply Voltage:
208-230/460 V
Motor Enclosure Type:
Open Drip Proof (ODP)
Rated Voltage:
208 V
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Insulation Class:
B
Duty Cycle:
Continuous
Efficiency:
82.2%
C Dimension:
12.3
Bearing Type:
6203
Rated Input Frequency:
60 Hz
Rated Input Frequency:
50 Hz
Motor Full Load Amps:
2.8-2.7/1.4 A
