Technical Specifications
Model:
FC51
Brand:
US Motors (Nidec)
Product Condition:
New
Horsepower Rating:
60 HP
Synchronous RPM:
1800 RPM
Rated RPM:
1785 RPM
Frame Size:
364TP
Rated Supply Voltage:
230/460 V
Motor Enclosure Type:
Weather Protected I (WP1)
Motor Design Class:
B
Full Load Torque:
176.7
Rated Voltage:
230 V
Rated Voltage:
460 V
Phase:
Three Phase
Service Factor:
1.15
Insulation Class:
F
Duty Cycle:
Continuous
Efficiency:
95%
Construction:
Cast Iron
C Dimension:
31.1
Bearing Type:
6211-J
Rated Input Frequency:
60 Hz
Motor Full Load Amps:
136/68 A
